91 XJ- Mystery plug, under dash, passenger side

Thread Tools

Search this Thread

Old 04-16-2016 | 09:27 PM
  #1
Bobburt's Avatar
Thread Starter
Newbie

Joined: Apr 2016
Posts: 7
Likes: 0
Model: Cherokee
Default 91 XJ- Mystery plug, under dash, passenger side

Under the dash on the passenger side, near the kick panel, there is a black mystery plug. This plug has 6 wires, and the plug itself is surrounded by black foam.

The 6 wires coming out of it are-

White
Black w/ green stripe
Black w/ blue stripe

Orange w/ black stripe
Blue w/ red stripe
Purple w/ green stripe


Maybe it has to do with the heater because of the foam? Other than that, I have no idea what this plug is for. Any ideas? Thanks.
Old 04-16-2016 | 10:32 PM
  #2
94zj318's Avatar
Senior Member

Joined: Feb 2012
Posts: 884
Likes: 44
From: Baltimore
Year: 2002
Model: Grand Cherokee
Engine: 4.0L (AMC) Straight Six
Default

They sound like speaker wiring, maybe that's a cable that plugs into a CD changer?
Old 04-16-2016 | 10:35 PM
  #3
Bobburt's Avatar
Thread Starter
Newbie

Joined: Apr 2016
Posts: 7
Likes: 0
Model: Cherokee
Default

I thought it might be related to the speakers or stereo, but none of the wire colors from this plug match to any stereo/speaker wires.

This is a 91 Cherokee Laredo. Did they come with CD changers back then?
