Heater Valve delete question?
When I eliminate the heater valve on a 95, can I simply hook up the 3/4
from the thermostat housing to the 3/4 on the heater core and then hook up
the 5/8 from the water pump to the 5/8 on the lower tube on the heater
core? Then plug the little vacumm hose?
The reason I ask is I found a video showing two reducer couplings being used, hooking the 3/4 to the 5/8ths and back.
This vid:
Or if I just wanted to completely eliminate the heater could I just hook the tube from the Thermostat housing to the water pump and then later reconnect the heater core?
Thanks.
from the thermostat housing to the 3/4 on the heater core and then hook up
the 5/8 from the water pump to the 5/8 on the lower tube on the heater
core? Then plug the little vacumm hose?
The reason I ask is I found a video showing two reducer couplings being used, hooking the 3/4 to the 5/8ths and back.
This vid:
Or if I just wanted to completely eliminate the heater could I just hook the tube from the Thermostat housing to the water pump and then later reconnect the heater core?
Thanks.
#2
Member
Join Date: Apr 2012
Location: Minersville Pennsylvania
Posts: 119
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1991
Model: Cherokee
Engine: 4.0 H.O.
I believe I used 5/8 or 3/4 hose on both sides, I didn't use a reducer. Yes you can eliminate the heater core if you want to do so. I'll see if the hose I used still shows the size.
#3
CF Veteran
Join Date: Nov 2009
Location: The Republic of TEXAS
Posts: 8,172
Likes: 0
Received 15 Likes
on
15 Posts
Year: 1998
Model: Cherokee
Engine: 4.0L HO
There r 2 hose sizes 5/8" and 3/4". Both sizes r readily available at any auto parts store. Get your tape measure out and measure hose lengths twice and cut once.
#4
Member
Join Date: Oct 2013
Location: Jasper AL
Posts: 237
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1988
Model: Cherokee
Engine: 4.0
If I remember correctly mine was on the end of a "T" arrangement made of metal. I took a hacksaw and cut the HCV off and slid hose down on metal part and double hose clamped it since it wasnt barbed. Been like that a year and no issues.
#5
Seasoned Member
Thread Starter
Join Date: Nov 2014
Location: So. Cal.
Posts: 333
Likes: 0
Received 0 Likes
on
0 Posts
Why, in this video does the poster say to connect the 5/8ths to the 3/4 and
use a reducer?????
Why not just hook up the same size lines together?
Is the heater core only one way, in and out?
use a reducer?????
Why not just hook up the same size lines together?
Is the heater core only one way, in and out?
Trending Topics
#9
CF Veteran
Join Date: Dec 2017
Posts: 4,038
Received 1,117 Likes
on
896 Posts
Year: 1989
Model: Comanche (MJ)
Engine: 4.0
What are you eliminating? Just the control valve and leaving the surge tank T'd off the lines? Fill the surge tank. If eliminating the surge tank, you need to provide a radiator cap and overflow bottle - either by swaping to the later radiator or installing one inline with the upper radiator hose.
