Maryland Cherokee Club
Senior Member
Join Date: Mar 2011
Location: Sykesville, MD
Posts: 590
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1990
Model: Cherokee
Engine: 4.0 L
Junior Member
CF Veteran
Join Date: Feb 2012
Location: Sykesville, Md
Posts: 2,961
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Cherokee
Engine: 4.0
Ok for those of you that still have working ac or had ac...is it normal for the compressor to cycle off after its been running for 10 min or so? My g/fs malibu does and wasnt sure if the xj did too. Blows cold air then starts warming up. Shut it off and after 15-20 min it blows cold again. Had it charged and pressure tested and passed with flying colors. Hoping i dont have a wiring issue, or maybe the high pressure sensor is bad... anybody have suggestions?
Seasoned Member
Join Date: Mar 2012
Location: Glen Burnie, MD
Posts: 411
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
Ok for those of you that still have working ac or had ac...is it normal for the compressor to cycle off after its been running for 10 min or so? My g/fs malibu does and wasnt sure if the xj did too. Blows cold air then starts warming up. Shut it off and after 15-20 min it blows cold again. Had it charged and pressure tested and passed with flying colors. Hoping i dont have a wiring issue, or maybe the high pressure sensor is bad... anybody have suggestions?
A pressure test involves evacuating the system putting it in a vacuum to remove as much refrigerant as possible. Then charge the system with nitrogen. probably around 250-300 psi. then watch to see if pressure drops. if it drops you have a leak.
You probably have a low charge or debri, or moisture in the system. All of wich can cause freezing in the evaporator and low pressure or possibly a high pressure issue on the discharge side.
Any good shop will cut to the chase and start from scratch. Its really the best way.
Gotta put gauges on it to see whats going on. Could be a bad condenser fan also.
Seasoned Member
Join Date: Mar 2012
Location: Glen Burnie, MD
Posts: 411
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
On another note. I got my new-used A/C line set installed and cold air a blowin. Also re-installed my hitch and adjusted the angle of my shackles on the relocation brackets. Im beat!
Seasoned Member
Join Date: Mar 2012
Location: Glen Burnie, MD
Posts: 411
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
Moderator of Jeeps
Join Date: Jul 2011
Location: Frederick, MD from Cleveland, OH
Posts: 21,029
Likes: 0
Received 3 Likes
on
3 Posts
Year: 1993 YJ Wrangler
Engine: 4.0 I6
Originally Posted by infohound
are you replacing yours yourself or using a shop? Are you using new parts or parts from salvage? I dunno what to do yet.
Senior Member
Join Date: Dec 2011
Location: kingsville
Posts: 675
Likes: 0
Received 0 Likes
on
0 Posts
Year: 91
Model: Cherokee
Engine: 4.?
Originally Posted by SDC
On another note. I got my new-used A/C line set installed and cold air a blowin. Also re-installed my hitch and adjusted the angle of my shackles on the relocation brackets. Im beat!
CF Veteran
Join Date: Sep 2011
Location: Frederick, MD
Posts: 10,447
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1989
Model: Cherokee
Engine: 4.0
Originally Posted by NewKindOfClown
Welcome to the overheating Renix club. I'm about to replace my cooling system, too.
Moderator of Jeeps
Join Date: Jul 2011
Location: Frederick, MD from Cleveland, OH
Posts: 21,029
Likes: 0
Received 3 Likes
on
3 Posts
Year: 1993 YJ Wrangler
Engine: 4.0 I6
Originally Posted by my89xj
I'm just going to throw a zj fan in there. Oh Tim you had some shims in that box to, do you need them?
CF Veteran
Join Date: Feb 2012
Location: Sykesville, Md
Posts: 2,961
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Cherokee
Engine: 4.0
Originally Posted by SDC
Who did the pressure testing and exactly what what did they do.
A pressure test involves evacuating the system putting it in a vacuum to remove as much refrigerant as possible. Then charge the system with nitrogen. probably around 250-300 psi. then watch to see if pressure drops. if it drops you have a leak.
You probably have a low charge or debri, or moisture in the system. All of wich can cause freezing in the evaporator and low pressure or possibly a high pressure issue on the discharge side.
Any good shop will cut to the chase and start from scratch. Its really the best way.
Gotta put gauges on it to see whats going on. Could be a bad condenser fan also.
Moderator of Jeeps
Join Date: Jul 2011
Location: Frederick, MD from Cleveland, OH
Posts: 21,029
Likes: 0
Received 3 Likes
on
3 Posts
Year: 1993 YJ Wrangler
Engine: 4.0 I6
Seasoned Member
Join Date: Mar 2012
Location: Glen Burnie, MD
Posts: 411
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
If it was topped off then that means there is a leak.
If it shutting off on a pressure switch it is seen in the gauges. If pressures look good then jump out one switch at a time. or test with a meter to see whats cutting it off. Is the compressor clutch still spinning or is it truly being shut off?
