Any of you have a link to or pages you can fax/scan then email me for the wiring schematics for a '91 XJ? I've spent some time on my personal Google machine without finding what I need. I'm trying to help 96ss2283 with the goatscrew wiring job the PO of his XJ did and I'd like to start off by looking at a clean schematic. What I need specifically is the sheet that shows the blower switch to blower wiring and the harness behind the dash including the cig lighter, radio, etc.
I am not asking for anyone to violate a copyright by posting up - just PM me if you have access to the resource. Any help is appreciated.
I am not asking for anyone to violate a copyright by posting up - just PM me if you have access to the resource. Any help is appreciated.
