Welding thread!!!!
#286
Member
Join Date: Mar 2012
Location: Ridgecrest Ca.
Posts: 202
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2001
Model: Cherokee
Engine: 4.0L
#289
Member
Join Date: Mar 2012
Location: Ridgecrest Ca.
Posts: 202
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2001
Model: Cherokee
Engine: 4.0L
#293
Member
Join Date: Mar 2012
Location: Ridgecrest Ca.
Posts: 202
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2001
Model: Cherokee
Engine: 4.0L
Check the tension on the push down **** over roller. Make sure the roller is the same for the wire size you use. Maybe check to tension on the spool of wire itself also. What wire speed are you running at?
#294
How old is the machine? It could be caused by the liner or the top if it's pretty bad.
Is that flux core wire or aluminum wire? Flux core uses the knurled groove on the wire, and aluminum almost requires a spool gun to feed correctly
Is that flux core wire or aluminum wire? Flux core uses the knurled groove on the wire, and aluminum almost requires a spool gun to feed correctly
#295
Seasoned Member
Join Date: Nov 2011
Location: Co
Posts: 343
Likes: 0
Received 2 Likes
on
2 Posts
Year: 1999
Model: Cherokee
alright guys need a little advice I finally get to get outside and practice will not mig and my wire keeps kicking up on the drive a roll
Attachment 238532
Attachment 238532
It looks like you're using a serrated drive roller. With that in mind, I'd be willing to bet the wire is sticking to the tip and your hitting the trigger to "unstick" it. When you hit the trigger the drive roll just winds up the wire in the machine.
I can't tell you how many times I've seen that issue, but I'm sure it's in the hundreds over the last 10 years working as fabrication head.
It also does look like aluminum wire? If so, a spool gun is required per the other posts.
Last edited by Boostwerks.com; 04-12-2014 at 03:41 PM.
#296
CF Veteran
Join Date: Apr 2012
Location: Ross Vegas, Ga
Posts: 1,843
Likes: 0
Received 2 Likes
on
2 Posts
Year: 2000
Model: Cherokee
Engine: 4.0 w/ tupy head
It looks like you're using a serrated drive roller. With that in mind, I'd be willing to bet the wire is sticking to the tip and your hitting the trigger to "unstick" it. When you hit the trigger the drive roll just winds up the wire in the machine.
I can't tell you how many times I've seen that issue, but I'm sure it's in the hundreds over the last 10 years working as fabrication head.
It also does look like aluminum wire? If so, a spool gun is required per the other posts.
#299
Seasoned Member
Join Date: Sep 2011
Location: West Bend, WI
Posts: 272
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1995
Model: Cherokee
Engine: 4.0 Litre
Can the cheap welder I have be the cause of having a hard time getting the puddle to flow and burn into both surfaces but then when I grind the weld down all I see is the seam of the top metal? Like if the welds aren't melting together. I am welding a patch into my roof for a sunroof delete and I'm about to go insane. I'm getting weld-to-patch seam and it isn't even ground flush yet. Suggestions?
