We had the thing back in, with the pins in, in 45 minutes. That's from rigging to the excavator with chains, to pulling the chains off. There's a trick to it, get one side close, and jam a prybar in the hole, to keep it close to in place, move to the other side, use a pry bar to line the second hole up, pin slides right in, then back to the first side, use the prybar to do the same positioning, bam, pin slides right in.
Then it was square! This was when I always found out that no matter how careful I was, all those passes ended up putting put a twist in it. lol
This where they get you, It looked like it was a specialty piece from a unique source bent with a radius specifically for that particular application. I would be curious, Thank you!
#1352
::CF Administrator::
Then it was square! This was when I always found out that no matter how careful I was, all those passes ended up putting put a twist in it. lol
This where they get you, It looked like it was a specialty piece from a unique source bent with a radius specifically for that particular application. I would be curious, Thank you!
This where they get you, It looked like it was a specialty piece from a unique source bent with a radius specifically for that particular application. I would be curious, Thank you!
The plates we ordered from our local steel sources, just gave them the dimensions of what we wanted, and the radius needed. They always oblige, LOL...
#1353
::CF Administrator::
Safety First
OK I posted this in a couple of other places, but I feel it's important enough to post here as well...
Just a small reminder as to why it's important to adhere to safety guys...
So the first picture, this happened during my most recent work re-skinning our grinder's hammermill cover...had to torch the old skin out, but the way it sat, all the molten metal and slag basically "ski-jumped" off the plate...now I was wearing long pants of course, and nothing really could be done other than stand off to the side...the pool of hot liquid metal rolled down off the plate, jumped off and onto my pant leg, burned through, and landed INSIDE my boot. Ouch.
Second pic, just showing a size comparison of the wound, yes that's a quarter...
Okay, third pic is entirely my fault. It has been triple digit temps and muggy here lately with the high humidity, not common here in the desert. I was working yesterday (Saturday) and being there on the weekend, I told myself "well I'm gonna be as comfortable as possible", so I wore short sleeves. That's an arc flash sunburn there folks. Only had about an hour and a half of welding to get that. So, my wanting to be "comfortable" for a few hours, now has me being uncomfortable for several days as it heals. So I nominate myself. LOL
Bottom line here is to be safe guys. This is what happens when you get lax in it. It sucks.
Just a small reminder as to why it's important to adhere to safety guys...
So the first picture, this happened during my most recent work re-skinning our grinder's hammermill cover...had to torch the old skin out, but the way it sat, all the molten metal and slag basically "ski-jumped" off the plate...now I was wearing long pants of course, and nothing really could be done other than stand off to the side...the pool of hot liquid metal rolled down off the plate, jumped off and onto my pant leg, burned through, and landed INSIDE my boot. Ouch.
Second pic, just showing a size comparison of the wound, yes that's a quarter...
Okay, third pic is entirely my fault. It has been triple digit temps and muggy here lately with the high humidity, not common here in the desert. I was working yesterday (Saturday) and being there on the weekend, I told myself "well I'm gonna be as comfortable as possible", so I wore short sleeves. That's an arc flash sunburn there folks. Only had about an hour and a half of welding to get that. So, my wanting to be "comfortable" for a few hours, now has me being uncomfortable for several days as it heals. So I nominate myself. LOL
Bottom line here is to be safe guys. This is what happens when you get lax in it. It sucks.
#1354
CF Veteran
Join Date: May 2015
Location: San Antonio, TX
Posts: 1,472
Likes: 0
Received 5 Likes
on
5 Posts
Year: 1992
Model: Cherokee
Engine: 4.0L H.O.
Damn Ronin, she got you good on the ankle there bud. Made my butt pucker seeing that pic, been there too many times.
The flash burn, lol, I'm guilty of that all the time. I know it's bad, but when it's 105 with 85% humidity... I really can't function in full covering.
The flash burn, lol, I'm guilty of that all the time. I know it's bad, but when it's 105 with 85% humidity... I really can't function in full covering.
#1355
CF Veteran
Join Date: May 2015
Location: Arizona
Posts: 4,481
Likes: 0
Received 18 Likes
on
14 Posts
Year: 97
Model: Cherokee
Engine: 4.0
Safety First!
That's a bad burn man, 3rd degree from what it looks like. That's a bad place for one too, especially in your business. Have you put any thought yet into how you are going to properly take care of that for the next 3-4 weeks? A dry scab could be a mistake with a wound that large my friend, been there.
#1356
::CF Administrator::
Damn Ronin, she got you good on the ankle there bud. Made my butt pucker seeing that pic, been there too many times.
The flash burn, lol, I'm guilty of that all the time. I know it's bad, but when it's 105 with 85% humidity... I really can't function in full covering.
The flash burn, lol, I'm guilty of that all the time. I know it's bad, but when it's 105 with 85% humidity... I really can't function in full covering.
That's a bad burn man, 3rd degree from what it looks like. That's a bad place for one too, especially in your business. Have you put any thought yet into how you are going to properly take care of that for the next 3-4 weeks? A dry scab could be a mistake with a wound that large my friend, been there.
Let me tell you, this stuff is a welder's best friend, LOL...it goes on like a cream (sort of) and keeps the wound "moist" but at the same time, forms a sticky skin over the top. I've been using it religiously. I only own two pair of shoes: work boots, and flip flops. So, in the AM, I apply liberally, and have been using brand new socks, gauze pads would be too bulky in my boots, lace up, and fortunately, it's in a spot that doesn't get aggravated too much...I don't even realize it's there during the day. Get home, pull my socks off, and they come right off, no sticking to the wound at all. Shower up, clean well, and reapply the ointment, and let it breathe until the next round. It's working great so far. My sis told me to go to the doctor, I said why...they're gonna pretty much tell me to do what I'm doing, and my niece, who's in nursing school ATM, said it looks good, so unless it becomes infected, I'm gonna roll with it. I hardly realize it's there, so why not?
#1358
CF Veteran
Join Date: May 2015
Location: Arizona
Posts: 4,481
Likes: 0
Received 18 Likes
on
14 Posts
Year: 97
Model: Cherokee
Engine: 4.0
Well done!
Let me tell you, this stuff is a welder's best friend, LOL...it goes on like a cream (sort of) and keeps the wound "moist" but at the same time, forms a sticky skin over the top. I've been using it religiously. I only own two pair of shoes: work boots, and flip flops. So, in the AM, I apply liberally, and have been using brand new socks, gauze pads would be too bulky in my boots, lace up, and fortunately, it's in a spot that doesn't get aggravated too much...I don't even realize it's there during the day. Get home, pull my socks off, and they come right off, no sticking to the wound at all. Shower up, clean well, and reapply the ointment, and let it breathe until the next round. It's working great so far. My sis told me to go to the doctor, I said why...they're gonna pretty much tell me to do what I'm doing, and my niece, who's in nursing school ATM, said it looks good, so unless it becomes infected, I'm gonna roll with it. I hardly realize it's there, so why not?
No pun intended, lol. You have it handled, I was going to suggest keeping a semi wet scab but I am not licensed to give medical advice. All three of my Daughters and one Son in law are advanced in the Medical Field and would completely agree with your assessment, care and treatment of this
On another note, I put too much load on a 100ft extension cord with my 6" grinder and started a fire yesterday, guess I was "Digging" into my grind too hard. lol
#1359
Member
Join Date: Feb 2015
Location: Knoxville, TN
Posts: 112
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1999
Model: Cherokee
i have a question for some of you guys.
I am going to be welding in my new floor pan to my frame. I have drilled holes in my new floor pan to plug weld to the frame...with that said...the metal of the frame is a thicker metal than the floor pan. Do I set my welder to the floor pan settings, or to the frame settings? I feel that if i set to floor pan setting, it wont get a good weld to the frame...if i do it to the frame settings, it will probably just burn holes through the floor pan.. ?????
I am going to be welding in my new floor pan to my frame. I have drilled holes in my new floor pan to plug weld to the frame...with that said...the metal of the frame is a thicker metal than the floor pan. Do I set my welder to the floor pan settings, or to the frame settings? I feel that if i set to floor pan setting, it wont get a good weld to the frame...if i do it to the frame settings, it will probably just burn holes through the floor pan.. ?????
Last edited by 93civEJ1; 09-15-2015 at 10:24 AM.
#1360
CF Veteran
Join Date: May 2015
Location: San Antonio, TX
Posts: 1,472
Likes: 0
Received 5 Likes
on
5 Posts
Year: 1992
Model: Cherokee
Engine: 4.0L H.O.
i have a question for some of you guys.
I am going to be welding in my new floor pan to my frame. I have drilled holes in my new floor pan to plug weld to the frame...with that said...the metal of the frame is a thicker metal than the floor pan. Do I set my welder to the floor pan settings, or to the frame settings? I feel that if i set to floor pan setting, it wont get a good weld to the frame...if i do it to the frame settings, it will probably just burn holes through the floor pan.. ?????
I am going to be welding in my new floor pan to my frame. I have drilled holes in my new floor pan to plug weld to the frame...with that said...the metal of the frame is a thicker metal than the floor pan. Do I set my welder to the floor pan settings, or to the frame settings? I feel that if i set to floor pan setting, it wont get a good weld to the frame...if i do it to the frame settings, it will probably just burn holes through the floor pan.. ?????
#1361
::CF Administrator::
Posted in a different area of the forum...but it fits here so here goes:
Okay so I was working on this
and had to remove this
from here
where I found this
and this...you can see the tear along the old weld
This was the piece that ripped off the first side
other side
so I took the plasma cutter and cut a new one out
tacked in place
other side prior to welding
the side that ripped, but not completely off
other side
the ripped side welded...not the prettiest, but there were gaps, I did what I could...
torn side 1 welded
torn side 2 welded
re-tabbed second side welded
broken mount on the front loader
the mount that broke
welded in place
A few things to remember...I was welding on a diesel tank...and the mount on the body of the loader was pretty tight for my large ***...but all is good and they are driving it, so BOOYAH
One other thing to mention...when I got the machine, that diesel tank was only being held on by a single bolt...one was missing, one tab sheared off, one mount block broken, and one bolt holding it all in...the reason I even noticed it was my compadre was doing a maintenance on it, and it had a bad hydraulic leak...so I told him to park it and I would investigate...during the troubleshooting I found all the broken mounts, but the other thing to remember is there was a leak...on the front of that fuel tank is a hydraulic oil cooler, which is cooled by the coolant...so there was hydraulic lines, coolant lines, fuel lines, and wiring for gauges. Made new hydraulic hoses for the bad ones that were leaking, put 'em in. All in an 8 hour shift. Yes I'm drinking a beer right now, LOL
Okay so I was working on this
and had to remove this
from here
where I found this
and this...you can see the tear along the old weld
This was the piece that ripped off the first side
other side
so I took the plasma cutter and cut a new one out
tacked in place
other side prior to welding
the side that ripped, but not completely off
other side
the ripped side welded...not the prettiest, but there were gaps, I did what I could...
torn side 1 welded
torn side 2 welded
re-tabbed second side welded
broken mount on the front loader
the mount that broke
welded in place
A few things to remember...I was welding on a diesel tank...and the mount on the body of the loader was pretty tight for my large ***...but all is good and they are driving it, so BOOYAH
#1362
CF Veteran
Join Date: May 2015
Location: Arizona
Posts: 4,481
Likes: 0
Received 18 Likes
on
14 Posts
Year: 97
Model: Cherokee
Engine: 4.0
One thing about that Business...Every piece of equipment has to be up and rolling ASAP. There is no such thing as "Spare" equipment. Know why it tore along the weld? For some reason everyone insists that they use high tensile hard rod on everything and it will not flex with the metal next to it. All this stuff flexes and the weld needs to flex with it.
Last edited by Bugout4x4; 09-17-2015 at 07:55 AM.
#1363
CF Veteran
Join Date: May 2015
Location: Arizona
Posts: 4,481
Likes: 0
Received 18 Likes
on
14 Posts
Year: 97
Model: Cherokee
Engine: 4.0
Sheet bending suggestions?
Here's what I am up against. I am just about done building a high clearance utility trailer to pull behind our Jeep. I am down to bending fenders and adding the lights I have some 12" wide x 1/16th inch sheet that was left over from a previous project and want to make some simple flat fenders with tight 45 degree bends.
I haven't ran into this situation much and I have to be honest and admit that my past attempts haven't been very clean. Does anyone have any suggestions or tricks on how to make good clean true bends in this slightly heavier sheet without me needing to first fabricate a Brake to do this?
I haven't ran into this situation much and I have to be honest and admit that my past attempts haven't been very clean. Does anyone have any suggestions or tricks on how to make good clean true bends in this slightly heavier sheet without me needing to first fabricate a Brake to do this?
#1364
No, I don't lick fish.
OK I posted this in a couple of other places, but I feel it's important enough to post here as well...
Just a small reminder as to why it's important to adhere to safety guys...
So the first picture, this happened during my most recent work re-skinning our grinder's hammermill cover...had to torch the old skin out, but the way it sat, all the molten metal and slag basically "ski-jumped" off the plate...now I was wearing long pants of course, and nothing really could be done other than stand off to the side...the pool of hot liquid metal rolled down off the plate, jumped off and onto my pant leg, burned through, and landed INSIDE my boot. Ouch.
Attachment 276017
Second pic, just showing a size comparison of the wound, yes that's a quarter...
Attachment 276018
Okay, third pic is entirely my fault. It has been triple digit temps and muggy here lately with the high humidity, not common here in the desert. I was working yesterday (Saturday) and being there on the weekend, I told myself "well I'm gonna be as comfortable as possible", so I wore short sleeves. That's an arc flash sunburn there folks. Only had about an hour and a half of welding to get that. So, my wanting to be "comfortable" for a few hours, now has me being uncomfortable for several days as it heals. So I nominate myself. LOL
Attachment 276019
Bottom line here is to be safe guys. This is what happens when you get lax in it. It sucks.
Just a small reminder as to why it's important to adhere to safety guys...
So the first picture, this happened during my most recent work re-skinning our grinder's hammermill cover...had to torch the old skin out, but the way it sat, all the molten metal and slag basically "ski-jumped" off the plate...now I was wearing long pants of course, and nothing really could be done other than stand off to the side...the pool of hot liquid metal rolled down off the plate, jumped off and onto my pant leg, burned through, and landed INSIDE my boot. Ouch.
Attachment 276017
Second pic, just showing a size comparison of the wound, yes that's a quarter...
Attachment 276018
Okay, third pic is entirely my fault. It has been triple digit temps and muggy here lately with the high humidity, not common here in the desert. I was working yesterday (Saturday) and being there on the weekend, I told myself "well I'm gonna be as comfortable as possible", so I wore short sleeves. That's an arc flash sunburn there folks. Only had about an hour and a half of welding to get that. So, my wanting to be "comfortable" for a few hours, now has me being uncomfortable for several days as it heals. So I nominate myself. LOL
Attachment 276019
Bottom line here is to be safe guys. This is what happens when you get lax in it. It sucks.
Nomex coveralls. This is a retired wildland firefighting jumpsuit. Last time I was under the jeep welding on my exhaust, I got several burns on my neck from slag. Nothing severe, just little pebble-sized burns, but they sucked. So I went to the department I used to volunteer for and asked if they had anything de-certified that I could pick up for a song. I know the inventory guy and he showed me some things they were going to toss out. Wound up with the coveralls, a Nomex hood, and a pair of structural gloves for a five-finger discount. I might look overdressed and/or ridiculous wearing full nomex coveralls and hood when I'm under the Jeep welding, but at least I'm not getting burnt. I can still feel some heat when slag drops on it, but it doesn't burn through, melt, or destroy the fabric. The suit is lightweight and breathable, for the most part. If you guys can get your hands on some, I'd highly recommend it.
Nomex hood on the Galls website is about 40 bucks, coveralls are normally about 300. Since the FD couldn't use these anymore, they were fair game.
ON TO THE WELDING!!!!
I think I'm showing improvement. Had to re-do my exhaust. My original welds, as awesome as they were just weren't holding up... plus, I traded a sword to a guy for a Thrush Turbo muffler so it was an opportune time to re-do things.
Welds went from this...
To this...
mmmmm.. penetration
The other end...
Bracket that I modified for the hanger that mounts to the transmission mount...
And the final product...
Not at all professional grade, but they'll hold this time. Which is the whole point anyway. I've got a lot of practicing to do to get my technique down, and of course a better welder would help, but I feel a lot more confident about my welds now and how to work the puddle.
Criticism welcome... remember, I'm using a Harbor Freight 90 amp flux welder with their crappy wire. The exhaust piping was done on the low-heat setting and the bracket was done on high-heat. Wire-feed speed on pipe between 4-5, and 5-6 on the bracket.
Last edited by Basslicks; 09-26-2015 at 04:31 AM.
#1365
Junior Member
Join Date: Aug 2015
Location: Mackay Australia
Posts: 43
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1995
Model: Cherokee
Engine: 4.0
Question regarding material.
I looking to use a set of old shackles to make an extended set for a couple of inch's lift on no budget. Its my daily driver for atleast the next 6 months and them will become our family weekend toy which will be redone with a proper 4-6" lift.
Plan is to either cut the existing legs of the shackles to weld new legs to the bush housing or extend the existing legs by welding a couple of pieces of either 1 x 1/4" or 1 1/4" x 1/4" flat bar to them.
Can I use plan old 250 grade mild steel or does it need to a higher grade? 250 is cheap and readily available in Australia
I looking to use a set of old shackles to make an extended set for a couple of inch's lift on no budget. Its my daily driver for atleast the next 6 months and them will become our family weekend toy which will be redone with a proper 4-6" lift.
Plan is to either cut the existing legs of the shackles to weld new legs to the bush housing or extend the existing legs by welding a couple of pieces of either 1 x 1/4" or 1 1/4" x 1/4" flat bar to them.
Can I use plan old 250 grade mild steel or does it need to a higher grade? 250 is cheap and readily available in Australia
