flex pics
#1426
Senior Member
Join Date: Jan 2012
Location: Lockhaven PA
Posts: 622
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1998
Model: Cherokee
Engine: 4.0
Ive done it, With my prior setup. And look at my picture in my post above, I currently only have a 4.5in setup now and look at the amount of droop My rear axle has using a stock leaf pack with a IRO aal, another stock XJ main leaf cut under my stock main for added support. RC Shackle relocation kit, and 1.5in shackle for lots of swing
With out the aal it sits about 3-3.5in with my same setup
With out the aal it sits about 3-3.5in with my same setup
#1427
Senior Member
Join Date: Jan 2011
Location: Lynchburg, VA
Posts: 653
Likes: 0
Received 1 Like
on
1 Post
Year: 1997
Model: Cherokee
Engine: 4.0L I6
BTW Its less wear on you spring pack this way. Inverting the packs over compressing shortens life heavily.
When it comes to flex some uptravel is nice but droop is the name of the game. Keeping all 4 wheels on the ground and the truck closer to level.
Last edited by Boost Happy; 04-23-2012 at 09:41 PM.
#1428
CF Veteran
Join Date: Nov 2010
Location: chillicothe, OH
Posts: 2,139
Likes: 0
Received 1 Like
on
1 Post
Year: 1991
Model: Cherokee
Engine: 4.0
Originally Posted by Boost Happy
Before you start you must first disassemble your leaf pack and inspect leaves for any wear. Importantly if you have a worn main leaf then go to a pick and pull and grab a good set of main leaves. take your old ones(or new ones if the old are good shape) and cut the eyes off them and install under your mains and reassemble. Then purchase 1.5in lift shackles, and also purchase a shackle relocation kit from HD enginering or Rough country. Assemble with a 35-45 angle with static load. Enjoy having one of the few Xj's with actually flex that no kit on the market offers.
BTW Its less wear on you spring pack this way. Inverting the packs over compressing shortens life heavily.
When it comes to flex some uptravel is nice but droop is the name of the game. Keeping all 4 wheels on the ground.
#1429
CF Veteran
Join Date: Mar 2010
Location: Jacksonville, FL
Posts: 6,685
Likes: 0
Received 5 Likes
on
5 Posts
Year: 92
Model: Cherokee
Engine: 4.0
Originally Posted by Disoriented Hillbilly
Im sure there are some bump stop adjustments to be made or ?????????
#1430
Senior Member
Join Date: Jan 2011
Location: Lynchburg, VA
Posts: 653
Likes: 0
Received 1 Like
on
1 Post
Year: 1997
Model: Cherokee
Engine: 4.0L I6
My front is nicely bumpstopped, But with my rear setup has had a issue with inverting. I have my stock bottom leaf(tow/overload leaf) flipped over so during uptravel by the time the pack flatten out fully, it is stopped by the overload. So in my case no bump stop needed. But in most cases I would recommend testing flex making sure leaves dont invert, if the start to invert then buy/make bumpstops.
Last edited by Boost Happy; 04-23-2012 at 09:53 PM.
#1434
Senior Member
Join Date: Aug 2011
Location: pennsylvania
Posts: 607
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1999
Model: Cherokee
Engine: 4.0L
Originally Posted by outlawtr450
factory leaf with extra main leaf, and 2" shackle and rc relocation boxes
#1435
CF Veteran
Join Date: Apr 2011
Location: Dayton Ohio
Posts: 2,080
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1998 classic
Model: Cherokee
Engine: 4.0!!
#1436
Senior Member
Join Date: Jan 2012
Location: Lockhaven PA
Posts: 622
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1998
Model: Cherokee
Engine: 4.0
id say it all depends on how saggy you stock leaf's are i got around 4.5" with the boxes and shackels and beefed up springs im clearing 31's with no problems, my jeep kinda looks funny cuz i have 3" in the front and 4.5 in the rear but it works for now
