Rims/Tires Swap out...Grabbers (red letters) getting stored
I found a guy with a 99 jeep wrangler with nice looking centerline type rims and new ATV tires on them. I went to myboltpattern.com and found the 96 cherokee (mine) and the 99 wrangler have same bolt pattern and lug pattern, and the only difference is the offset range. Here is the info for both vehicles:
5X4.50 inches
5X114.3 mm
71.5 front and rear center bore
1/2X20 stud size
Here is the difference:
96 cherokee 0 to 25 offset
99 wrangler 0 to 30 offset
Now here is my question for this... can I use these rims from a 99 wrangler with a 0 to 30 mm offset range on my 96 cherokee that is a 0 to 25 mm offset range? I don't even understand that part of the rims swap out much less its hard enough to change my tires without breaking a nail as it is.
please help?
5X4.50 inches
5X114.3 mm
71.5 front and rear center bore
1/2X20 stud size
Here is the difference:
96 cherokee 0 to 25 offset
99 wrangler 0 to 30 offset
Now here is my question for this... can I use these rims from a 99 wrangler with a 0 to 30 mm offset range on my 96 cherokee that is a 0 to 25 mm offset range? I don't even understand that part of the rims swap out much less its hard enough to change my tires without breaking a nail as it is.
please help?
CF Veteran
Join Date: Jul 2010
Location: 802
Posts: 4,930
Likes: 0
Received 3 Likes
on
3 Posts
Year: 99
Model: Cherokee
Engine: 4.0
I found a guy with a 99 jeep wrangler with nice looking centerline type rims and new ATV tires on them. I went to myboltpattern.com and found the 96 cherokee (mine) and the 99 wrangler have same bolt pattern and lug pattern, and the only difference is the offset range. Here is the info for both vehicles:
5X4.50 inches
5X114.3 mm
71.5 front and rear center bore
1/2X20 stud size
Here is the difference:
96 cherokee 0 to 25 offset
99 wrangler 0 to 30 offset
Now here is my question for this... can I use these rims from a 99 wrangler with a 0 to 30 mm offset range on my 96 cherokee that is a 0 to 25 mm offset range? I don't even understand that part of the rims swap out much less its hard enough to change my tires without breaking a nail as it is.
please help?
5X4.50 inches
5X114.3 mm
71.5 front and rear center bore
1/2X20 stud size
Here is the difference:
96 cherokee 0 to 25 offset
99 wrangler 0 to 30 offset
Now here is my question for this... can I use these rims from a 99 wrangler with a 0 to 30 mm offset range on my 96 cherokee that is a 0 to 25 mm offset range? I don't even understand that part of the rims swap out much less its hard enough to change my tires without breaking a nail as it is.
please help?
Last edited by VTJeep; 11-13-2015 at 11:29 AM.
Junior Member
Join Date: Jul 2013
Location: Los Angeles, California
Posts: 31
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1996
Model: Cherokee
Engine: 4.0L, 6cyl., performance chipped
okay i appreciate the answer. I am going to go for it since 5 mm is not that far off. I assume they will fit and get me through my city driving for a good season or two until I decide to bring back the grabbers for the fun stuff. Thank you for the help.
CF Veteran
Join Date: Jul 2010
Location: 802
Posts: 4,930
Likes: 0
Received 3 Likes
on
3 Posts
Year: 99
Model: Cherokee
Engine: 4.0
You got it! 5mm=.19685" or .2" or 1/5" so very minimal change. The difference, however, is that the rim is tucked inward by that amount. This will move the wheel closer to your control arms and the wheel well. Make sure to check clearance issues before setting out to wheel. Turn lock to lock and see if there is any scrubbing issues and flex it out to see if theres clearance issues height wise.. Id put my money at 0 problems if tires are stock size.
Junior Member
Join Date: Jul 2013
Location: Los Angeles, California
Posts: 31
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1996
Model: Cherokee
Engine: 4.0L, 6cyl., performance chipped
Awesome information which makes me feel better already about purchasing these. I am off to the bank now to get the cash so thanks guys for the prompt responses and I will report back if there is a problem, otherwise, happy jeeping and happy holidays.
CF Veteran
Join Date: Jul 2010
Location: 802
Posts: 4,930
Likes: 0
Received 3 Likes
on
3 Posts
Year: 99
Model: Cherokee
Engine: 4.0
Cheers to that! Just make sure to post up pics!
No, I don't lick fish.
Actually if you compare their 4.5" kits, they pretty much come with all the same parts.
RC's kit used to only come with brake line relocation brackets but they've since updated it to include new front/rear brake lines.
RC also changed up their trackbar setup which necessitated them adding a drop pitman arm to their kit too, whereas RE's kit doesn't need or use a drop pitman arm.
RE uses a combo of shorter leafs and lift shackles for their rear lift though (which IMHO is a better way to go) vs RC's full 4.5" leafs that use the stock shackles.
FWIW we seem to have more customers come back and buy replacement bushings and flex joint rebuild kits for their RC arms than we do for RE arms.
Also, we're going to be running a promo on RE kits w/shocks soon - I'll post up about it in the vendor forum here in the next day or three.
RC's kit used to only come with brake line relocation brackets but they've since updated it to include new front/rear brake lines.
RC also changed up their trackbar setup which necessitated them adding a drop pitman arm to their kit too, whereas RE's kit doesn't need or use a drop pitman arm.
RE uses a combo of shorter leafs and lift shackles for their rear lift though (which IMHO is a better way to go) vs RC's full 4.5" leafs that use the stock shackles.
FWIW we seem to have more customers come back and buy replacement bushings and flex joint rebuild kits for their RC arms than we do for RE arms.
Also, we're going to be running a promo on RE kits w/shocks soon - I'll post up about it in the vendor forum here in the next day or three.
Anything bigger than 31x10.5 will require some amount fender trimming, it may just be trimming some plastic inside the wheel well or on the backside of the bumper and wheel well liner.
Also keep in mind bigger tires will require you to recalibrate your speedometer and you'll loose a bit of power and fuel economy, and 33s are big enough to start looking into regearing your axles.
Newbie
Join Date: Apr 2015
Location: West virginia
Posts: 6
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1998
Model: Cherokee
Engine: 4.0 inline 6
Yeah as of now i habe three inch wheel spacers so they dont rub I forgot about regearing my axles and they do rub a little on my fender trim might just buy some meaner looking tire but same size
Thanks again man!
Thanks again man!
Senior Member
Join Date: Feb 2014
Location: Minnesota
Posts: 854
Likes: 0
Received 1 Like
on
1 Post
Year: 1996
Model: Cherokee
Engine: 4.0
CF Veteran
Join Date: Jul 2010
Location: 802
Posts: 4,930
Likes: 0
Received 3 Likes
on
3 Posts
Year: 99
Model: Cherokee
Engine: 4.0
ugh! Agreed- ditch the spacers. Adaptors if you refuse to get a rim with less BS! Usually 4.00-3.75" is sufficient. It will give you the same profile you have now. As for the tires a 32x11.50 is the next step size wise, but a 33x10.50 or 12.50 seems like a more common move. You could always get some 33x15.50 TSL's!
